The NLCSPSS1WH is a low-voltage Bluetooth wireless PIR/Daylight sensor designed for seamless integration with NICOR sensor-ready fixtures, making it perfect for your Luminaire Level Lighting Controls (LLLCs) needs. Constructed from the highest-rated fire retardant material, this sensor offers easy installation and use, providing 360° coverage at heights ranging from 8 to 18ft. Setup and commissioning requires the NICOR NLC mobile app (Android/iPhone).



Categories: Tag:

Specifications

  • Bluetooth 5.0 mesh network with 100ft open-air range
  • Dual PIR/Daylight sensor with 360° coverage from 8–18ft mounting height
  • Tool-free snap-in installation on NICOR sensor-ready fixtures
  • Managed via NICOR NLC app on iOS and Android
  • Scales to 100 luminaires, 20 groups, and unlimited zones per installation
  • Settings saved on-device — system runs through power outages and network drops
  • Fire retardant plastic housing, IP20 rated, -22°F to 131°F operating range
  • cULus Listed, DLC NLC5, UL1376 Cyber Security Certified, RoHS compliant — 5-year warranty



Part Number:

NLCSPSS1WH

Downloads

– Spec Sheet
– Installation Instructions
